U Carve

Price range: £208.05 through £219.00

The AFS U-Carve is a compact, surf-centric stabilizer designed for fluid rail-to-rail transitions and effortless flow. Its reduced wingspan and upturned winglets offer a free-rolling, playful feel in the waves while maintaining rock-solid tracking and continuous support at both high and low speeds.

Category: ,
Brands:

Description

The U-Carve Stabilizer is all about delivering an intuitive, loose, and ultra-natural carving experience on the wave. Designed with a generous “full base” footprint, it offers exceptional rigidity and precise underfoot support. By reducing the wingspan and refining the tips, designer Laurent Borgna has refocused the lift—completely freeing up the board’s side-to-side roll for a highly playful, surf-like feel. It’s the ultimate choice for committed wingers, surf foilers, and downwind riders who want fluid rail-to-rail transitions without sacrificing control.

Why it stands out:

  • Surfy Roll Control: A compact wingspan frees up side-to-side movement for incredibly natural turning.

  • Rigid Full-Base Design: A generous footprint ensures maximum stiffness and a highly responsive feel.

  • High-Speed Winglets: Upturned tips reduce drag and turbulence, eliminating unwanted twitchiness at top speeds.

  • Low-Speed Support: The optimized profile maintains reliable lift and progressive support, preventing the foil from “stalling out” in lulls.

  • Universal Match: Built in premium monolithic carbon and fully compatible with all standard AFS fuselages.



Surface area (cm2) Span (mm) Aspect Ratio Cord max (mm) Thickness (mm) Construction Weight (kg) Screw size (mm) Compatibility
130 360 10 68 5 HR Carbon + HM Carbon / Monolithic 0.1 12mm Torx 30 All AFS fuselages
140 375 10 72 5 HR Carbon + HM Carbon / Monolithic 0.1 12mm Torx 30 All AFS fuselages
150 390 10 76 5 HR Carbon + HM Carbon / Monolithic 0.1 12mm Torx 30 All AFS fuselages
160 400 10 80 5 HR Carbon + HM Carbon / Monolithic 0.1 12mm Torx 30 All AFS fuselages
